Product Code : VF--JCC-J8-CU
Product model: YJ41W
Nominal diameter: DN15~500mm
Nominal pressure: PN1.6~4.0MPa
Applicable medium: oxygen
Applicable temperature: 0℃-80℃
Body material: stainless steel, copper alloy
Flange standard: GB/T9113, JB/T79
Manufacturing standard: GB/T 12235
Structure standard: GB/T 12221
Widely used in steel, metallurgy, petrochemical, chemical and other oxygen engineering pipe network
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Product characteristics
1, in addition to the function of ordinary valves, but also has its own characteristics.
2. Strict oil prohibition measures are adopted during manufacturing, and all parts are strictly degreased before installation.
3, all diameter valve flange end is provided with conductive screw holes to prevent static electricity.
4, the exposed parts of the valve have protective measures to prevent dust and oil pollution.
5, the materials used are divided into two categories: one is the selection of cast silicon brass for the valve body, valve cover, valve disc materials; The other is the selection of high-quality stainless steel for the valve body, valve cover, valve disc materials.
Oxygen special globe valve is mainly used to connect or cut off the medium in the pipeline, generally do not need to adjust the flow, but the applicable pressure range is very wide. This is a special valve specially designed for oxygen pipe network, which is widely used in steel, metallurgy, petrochemical, chemical and other oxygen engineering pipe network. In addition to the function of ordinary valves, it has its own characteristics. Strict oil prohibition measures are adopted during manufacturing, and all parts are strictly degreased before installation. All valve flanges are provided with conductive screw holes to prevent static electricity. The exposed part of the valve has protective measures to prevent dust and oil pollution.
Packing of Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 470 gallon liquid totes Special package is available on request. E FORUs’ is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
