J41F46 lined with fluorine globe valve, lined with fluorine globe valve

J41F46 Fluorine lined globe Valve Product Introduction:

It is suitable for various concentrations of aqua aqua, flowing acid, hydrochloric acid, hydrofluoric acid and various organic acids, strong acids and strong oxidants at -50~150℃, and is also suitable for various concentrations of strong alkali organic solvents and other corrosive gases and liquid media.

In order to ensure that the pipeline medium is absolutely not in direct contact with the valve shell material, the valve body, valve cover, valve disc and other internal parts of this product are designed into fluoroplastic lining parts; The valve seat uses integral polymer as sealing material, which has excellent sealing performance in a wide temperature and

pressure range; This series of valves has complete specifications and excellent corrosion resistance, and is the ideal valve for chemical, pharmaceutical, electronic, environmental protection, petrochemical, crude oil and natural gas transmission pipelines.

Product implementation standards:

a. Design specification: GB/T 12233 GB/T 12235

b. Structure length: GB/T 12221

c. Connection flange: JB/T 78 JB/T 79

d. Test and inspection: GB/T 13927

e. Product ID: GB/T 12220

f. Supply specification: JB/T 7928

J41F46 Fluorine-lined globe valve design features:

It has the advantages of compact structure, flexible opening and closing, strong corrosion resistance, short stroke (generally nominal diameter 1/4), etc., and is widely used in petroleum, chemical and other pipeline systems to cut the medium, but it needs to be emphasized that the fluoroplastic lined stop valve is strictly prohibited to be used for flow regulation, so as to avoid high-speed medium flow erosion and damage to the sealing surface at the throttle.

The disc and stem are designed as an integrated structure to prevent the possibility of the internal parts rushing out of the valve body caused by the fluctuation of pipeline pressure, compact structure and safe use.

It is suitable for various concentrations of aqua aqua, flowing acid, hydrochloric acid, hydrofluoric acid and various organic acids, strong acids and strong oxidants at -50~150℃, and is also suitable for various concentrations of strong alkali organic solvents and other corrosive gases and liquid media.

Packing of Standard Packing:

Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 470 gallon liquid totes Special package is available on request. E FORUs’  is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition
