FDJ41H Anti-theft Globe Valve Product Introduction:

According to the failure of the unit to pay in time and the loss caused by the time of oil theft, the valve products are developed and designed successfully. That is, lock the anti-theft stop valve, because there is no mechanical connection between the operating handwheel and the valve stem, the handwheel can be removed after the operation is completed. Unique technical structure, so that the magnetic torque valve with zero leakage, anti-theft, self-locking functions.

Applicable to nominal pressure ≤1.6MPa and ≤2.5MPa medium temperature 1~200℃ and ≤350℃ steam water pipe as throttling.

Design features:

According to the failure of the unit to pay in time and the loss caused by the time of oil theft, the valve products are developed and designed successfully. The company's anti-theft stop valve has good anti-theft performance, can achieve zero leakage, easy switch, stable sealing effect, long service life and so on.

After the anti-theft stop valve is installed, take the accessory wrench and set it in the keyway at the top of the valve to open (or close) the gate of the valve, close clockwise and open counterclockwise.

Zero leakage: the application of "no leakage transmission technology", the opening and closing system is sealed inside the valve body, rotate the special handwheel, complete the opening and closing operation of the valve, and completely eliminate the leakage;

Anti-theft: Since there is no mechanical connection between the special handwheel and the valve stem, the handwheel can be removed and taken away after the operation is completed, which can avoid misoperation and play an anti-theft role, easy to control and manage;

How to use: After the installation of the anti-theft valve, take the small hexagonal screw on the upper end of the accessory wrench to screw out the small hex screw on the valve cover, remove the lid, and the middle is the lock core, such as the lock core with the key to open, such as the password lock core (see the password formulation and use of the anti-theft valve), after taking out the lock core, use the lower end of the accessory wrench to open (or close) the valve, clockwise off, counterclockwise open.

Password lock: The use of magnetic field polarity, strength change and mechanical size design of different characteristics, can make the product have a "password lock" function, that is, the specified valve can only be opened with the specified hand wheel, to achieve "one valve one key", "multiple valves one key";

Long service life: Because the valve realizes the full sealing mechanism, cancels the packing, reduces the valve stem wear, makes the valve open and close flexibly, and does not show death, prolongs the service life of the valve;

Environmental protection and pollution-free: due to the elimination of leakage, the working environment of the site has been changed, and the pollution problem of the site has been solved. It is a really green environmental protection valve.

FDJ41H Anti-theft globe valve product working principle:

Locking valve according to the "rotation no leakage theory", using the push-pull magnetic circuit optimization design scheme, the traditional valve opening and closing operation mechanical force into torque, by rotating the special handwheel, drive the shield of the inner magnetic yoke (connected with the valve stem as one) rotation, complete the valve opening and closing. Because the opening and closing mechanism is closed inside the valve, the original dynamic seal (packing) is cancelled, so the external leakage of the valve is fundamentally eliminated. Because there is no mechanical connection between the operating handwheel and the valve stem, the handwheel can be removed after the operation is complete. Unique technical structure, so that the magnetic torque valve with zero leakage, anti-theft, self-locking functions.

Applicable to nominal pressure ≤1.6MPa and ≤2.5MPa medium temperature 1~200℃ and ≤350℃ steam water pipe as throttling.
