Product Code : VF--XCC-X30-CU
1. The structure of the valve is straight through
2. The design standard is in accordance with API599 and API6D
3. Structure length shall be in accordance with ASME B16.10
4. Flange connection shall comply with ANSI B16.5
5. The inspection standard shall comply with the requirements of API598 and API6D.
Applicable to natural gas pipelines with engineering pressure class CLASS150-900LB, PN10-PN150 and working temperature of – 29-150 ℃.
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
For the pressure balanced inverted oil seal plug valve, the position of the valve plug is adjusted by the bolt in the bonnet, and the sealant is injected into the valve body from the end of the valve stem; In order to prevent the pressure from pushing the valve plug into the valve body, a balance hole is opened at the end of the valve plug, while the balance hole at the small end of the valve plug has no medium and can only reach the check valve at the end of the small end, which can make the pressure enter the cavity at both ends of the valve plug, and the valve is sealed by the sealant between the valve plug and the valve body.
Applicable to natural gas pipelines with engineering pressure class CLASS150-900LB, PN10-PN150 and working temperature of – 29-150 ℃.
Packing of Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 470 gallon liquid totes Special package is available on request. E FORUs’ is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
