Product Code : VF--ZCC-Z42-CU
Pressure sealed valves are designed in combination with API/BS and ASME B16.34 standards and are widely used in high temperature and high pressure applications. Compact structure, sufficient strength, relatively competitive maintenance costs, and reliable sealing of the body cover.
Caliber range: 2""~40""(DN50~DN1000)
Pressure CLASS: ASME CLASS 600~4500 (PN100~PN760)
Main material: carbon steel, alloy steel, low temperature steel, double phase steel, nickel base, titanium alloy, etc
Connection mode: RF, BW, RTJ, etc
Operation mode: manual, gear drive, pneumatic, electric and hydraulic, etc
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Structural features:
1. The middle cavity of PN≤16Mpa adopts flange connection;
The middle cavity of PN≥20Mpa adopts pressure self-tightening seal;
2. Elastic gate.
3. The valve stem has an upper sealing function.
4. The sealing surface is overlayed with CR13, carbide or body, which is wear-resistant, high-temperature resistant and has long service life.
Flange connected gate valve is suitable for nominal pressure ≤42Mpa
It is used as a medium for cutting off or connecting pipelines on pipelines of various systems such as petroleum, chemical industry, thermal power stations, etc. with an operating temperature of ≤650°C.
It is used as a medium for cutting off or connecting pipelines on pipelines of various systems such as petroleum, chemical industry, thermal power stations, etc. with an operating temperature of ≤650°C.
