Product Code : VF--QCC-Q45-CU
Product name: Screw float ball valve
Product model: AF-89
Nominal diameter: DN15 ~ DN300
Structure: lever type
Nominal pressure: 0.03Mpa ~ 1.6Mpa
Connection mode: flange
Applicable temperature: ≤100ºC
Drive mode: Liquid level control
Body material; Stainless steel
Applicable media: water, oil, liquid
According to user needs can provide the use of medium temperature ≤150ºC,DN40~DN300 various specifications of high temperature float ball valve)
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
The screw float ball valve adopts stainless steel die-casting technology, so that the components are well-coordinated, there is no corrosion loose or tight jam phenomenon, to ensure that the ball valve works stably for a long time, and the design of stainless steel components makes the ball valve work in high humidity environment without chemical corrosion reaction, so that the water is pure and healthy.This product is specially improved float connecting rod form, adding the level adjustment gear rod group, so that the liquid level of the pool can be arbitrarily adjusted within the length range of the adjustment rod to meet the needs of different situations.Double lever buoyancy drive, so that the ball buoyancy drive has been multiplied, sealing pressure up to 8kg or more, much higher than the national standard of 6kg sealing pressure. And with the vertical valve core stable transmission, the float valve is easy to fail due to the unbalanced force of the valve core, and ensure the reliability of the float valve
Screw float ball valve using hydraulic principle design, with compact structure, open, close action reliable, high sensitivity, small head loss, no water hammer phenomenon and other advantages, but also with light weight, small size, easy installation and maintenance and other characteristics, widely used in industrial and mining enterprises, civil buildings all kinds of water tanks, pools, water tower automatic water supply system, can also be used as atmospheric boiler circulation water supply control valve.
