Side hard sealed fixed ball valve is split structure. This series of ball valves is suitable for 150LB~2500LB, and the temperature range is from -46~450℃. Fixed metal hard seal ball valve seat for metal hard seal structure, after hardening has the characteristics of high temperature and wear resistance, suitable for high temperature, corrosive media or granular media working conditions.
Caliber range: 2""~48""(DN50~DN1200)
Pressure CLASS: ASME CLASS 150~2500 (PN16~PN420)
Main material: carbon steel, stainless steel, alloy steel and duplex steel, nickel-based alloy, etc
Connection form: flange end, butt welding end, etc
Operation mode: manual, pneumatic, electric and hydraulic, etc
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
Design standard:
Design According: ASME B16.34/API 6D
Test According: API 6D
RF End: ASME B16.5
BW END: ASME B16.25
Face to Face: ASME B16.10
Anti-Fire Test According: API 607/API 6FA
Acid environment: NACE MR 0175
Advantages:
The side-mounted fixed ball valve adopts a two-piece or three-piece split side-mounted design, which conforms to the API6D standard, especially suitable for large-diameter, high-pressure pipeline fluid control, this series of fixed ball valves have double blocking and relief functions.
Packing of Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 2022 gallon liquid totes Special package is available on request. E FORUs’ is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
