Q41N high pressure forged steel ball valve,High pressure forged steel ball valve, forged steel high pressure ball valve, ball valve,Q41 ball valve

Q41N high pressure forged steel ball valve is mainly used for long-distance pipeline transportation of oil and natural gas and urban gas pipeline system. Due to the unique characteristics of the valve for long distance pipeline, its ability to withstand pipeline stress, as well as safety, weather resistance, long-term reliability of the sealing design structure is fully considered in the design. The driving mode can be manual, worm gear, pneumatic, electric, connection mode can be selected flange, welding, structural form is three-stage, sealing structure can be selected soft seal, hard seal, pressure range PN1.0-32.0Mpa, nominal diameter is DN10-200mm, the material can be selected forged steel, forged stainless steel. Due to the wide range of use of valves, the same valve has different combinations in different occasions and working conditions. High pressure forged steel ball valve is a ball with a circular channel as the opening and closing parts, the ball rotates with the valve stem to achieve the opening and closing action of the valve, both forward rotation 1/4 turn (90°), the valve is closed. Reverse rotation 1/4 turn (90°), the valve opens. The opening and closing part of the ball valve is a sphere with holes, rotating around the axis perpendicular to the channel, so as to achieve the purpose of opening and closing the channel. Ball valves are mainly used for opening and closing pipes and equipment media.

Q41N high pressure forged steel ball valve is mainly used for long-distance pipeline transportation of oil and natural gas and urban gas pipeline system. Due to the unique characteristics of the valve for long distance pipeline, its ability to withstand pipeline stress, as well as safety, weather resistance, long-term reliability of the sealing design structure is fully considered in the design.

Packing of Standard Packing:

Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 470 gallon liquid totes Special package is available on request. E FORUs’  is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
