Z41F46 anti-corrosion fluorine lined gate valve

Product characteristics

1, the valve body has flat body and round body two shapes: GB valve using round body, ANSI pound class valve DN≤300Lb flat body, DN≥400Lb using round body, valve body, valve cover cavity and gate, stem external surface and other parts directly in contact with the medium, all name lined FEP (F46) and other fluorine plastics;

2, the sealing pair is FPF (F46)/FEP (F46) or other material combination, the friction coefficient is small, the opening and closing torque is low;

3, packing PTFE (F4) standard packing, good sealing performance, easy maintenance and replacement;

4, with the elastic gate, can compensate the wedge Angle deviation between the gate sealing surface and the seat sealing surface, good coincidence, sealing effect is ideal;

5, the medium can pass through the gate valve from both sides in any direction, which is suitable for the opening and closing device on the pipeline where the direction of the medium may change.

Z41F46 anti-corrosion lined fluorine gate valve is suitable for various concentrations of aqua aqua, sulfuric acid, hydrochloric acid, hydrofluoric acid and various organic acids, strong acids, strong oxidants at -50℃~150℃, FEP is also suitable for various concentrations of strong alkali organic solvents and other corrosive gases, liquid media pipe use.

Packing of Standard Packing:

 Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 2022 gallon liquid totes Special package is available on request. E FORUs’  is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
