Product Code : VF--DDW-N1007-CU
Product overview
Q41H-16C-DN25 is a stainless steel hard sealed flange ball valve made of WCB material, mainly used to cut off or connect the medium in the pipeline. The valves are designed to provide excellent sealing performance and long service life for a wide range of industrial applications
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Main use
Operating temperature range: -29~425°C (carbon steel) or -40~550°C (stainless steel)
Applicable media: water, steam, oil, nitric acid, acetic acid, oxidizing medium, urea, etc
Application field
spaceflight
Chemical engineering
petroleum
metallurgy
machine
electricity
corpuscle
Water supply and other industries
Technical parameter
Nominal diameter and pressure rating
Nominal diameter: DN25
Pressure rating: 1.6MPa
Material specification
Body material: WCB (cast steel)
Sealing surface material: Cr13 series stainless steel
Design feature
Structural form
Floating ball valve: Angle of 90°, with good sealing performance and flow coefficient 3
Sealing performance
The sealing ring made of polytetrafluoroethylene and other materials is easy to seal, and the sealing capacity increases with the increase of medium pressure
Installation and maintenance
Installation requirements
The flange connection dimensions must meet relevant standards to ensure secure and reliable installation
Packing of Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 2018 gallon liquid totes Special package is available on request. E FORUs’ is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
